Product Details:
|
| Product Name: | LS-450plus Multi-Function Packaging Machine For Paper Box Packing & Book Cover & Cellphone Box | Type: | Multi-Function Packaging Machine |
|---|---|---|---|
| Working Speed: | 15-38 Pcs/min | Application: | Case Positioning And Gluing |
| Dimension(L*W*H):: | L5980*W3185*H2104 | Weight Of Machine: | 2141kg |
LS-450plus Multi-Function Packaging Machine For Paper Box Packing & Book Cover & Cellphone Box
Introduction:
LS-450plus is a multi-function visual positioning machine. It is able to positioning the rigid box and hardcover. also can do paper lining, one machine with many functions, and the working model is able to be changed by one button. The visual positioning system is able to be upgraded. Moreover, this machine also can be upgraded to an automatic line in the future if needed.
Equipped with dual cameras, the cameras are located on both sides of the central position of the conveyor belt. The camera position has been calibrated before leaving the factory. If there is any deviation, you can adjust the camera position by adjusting the upper camera "mounting plate". After the camera takes a picture, the system recognizes the color difference of the photo for positioning. If the surface paper and the surface paper conveyor belt are similar in color, it can be solved by changing the belt color.
The machine has two conveying systems, which are widely applicable. One conveys boxes, and the other conveys album covers and book covers (hardcover/book covers). The machine has a key to switch modes. It can be used to make boxes or leather cases (hardcover/book cover), and to change the working mode, it only needs to switch with one button, which is easy to operate and saves working time. The machine not only guarantees the customer in terms of operating efficiency, but also solves the customer's concerns about how the machine operates.
The machine is multifunctional, not only used by manufacturers who produce boxes, but also for factories that produce book covers, it is the best choice for customers
| Type | LS-450plus |
| Paper size (Max) | L800*W600mm |
| Paper size (Min) | L135*W100mm |
| Max box size | L600*W400*H120mm |
| Min box size | L80*W65*H15mm |
| Book cover (Max) | L750*W450mm |
| Book cover (Min) | L150*W100mm |
| Paper thickness | 100-350g/㎡ |
| Paper stacking height | 280mm |
| Motor power / voltage | 7.5kw/380v, 3 phase |
| Heating power | 8kw/380v, 3 phase |
| Air supply | 10L/min 0.6Mpa |
| Working speed | 15-45 sheets/min |
| Machine dimension | L5980*W3180*H2100mm |
| Weight of machine | 2100kg |
Company profile:
Dongguan Longxingjian Intelligent Equipment Co.,Ltd
We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd.
We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery's research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.
We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.
Our service:
Pre-sale service:
* Inquiry and consulting support.
* Sample testing support.
* Factory visit.
After-sale service:
* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* Free machine parts replacement during warranty.
* Whole life of machine service.
