Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Earing Gift Candy Preium Box Making Machine With Visual Positioning | Positioning Accuracy: | 0.01mm |
|---|---|---|---|
| Paper Thickness: | 80-350gsm | Cardboard Thickness: | 0.8-3mm |
| Material: | Steel | Warranty: | One Year |
| Condition: | New Machine | Color: | Black And White |
| Highlight: | Earing Gift Box Making Machine,Gift Box Making Machine 0.8mm,rigid box machine 3mm |
||
What is the Setting speed of one fully automatic rigid box making machine operator need? 3 hours, 2 hours or short time. we have machine the LS-1246D can producing the rigid box with shorter setting time.
As increasing of rigid box market, it have meet the situation that more and more orders and few experienced engineer of machine operating. It is the reason why we developing the LS-1246D, for high speed and intelligent setting.
With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
