Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Gift Cake Making Machine With Dual Box Wrapping System | Min Paper Size: | L120*W100mm |
|---|---|---|---|
| Max Cardboard Size: | L800*W600mm | Min Cardboard Size: | L120*W110mm |
| Dimension(l*w*h): | 6610x4250x3000 Mm | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Warranty: | 1 Year | Condition: | New Model |
| Voltage: | 380V 3 Phase | ||
| Highlight: | rigid gift cake box making machine,cake box making machine L120mm,Rigid box making machine W110mm |
||
LS-1246D is smart choice for gift box, ring box, T-shirt box, rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
LS-1246D Automatic smart rigid gift wedding box making machine with dual box wrapping system is an ideal machine for customer who has changable orders.
It including the box corner pasting, paper gluing, box positioning, box wraping and pressing at one time. This machine has applied visual positioning for easy and high accurate positioning. Automatic setting in the forming station make the whole machine setting time reduce grealty.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
