Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Cellphone Perfume Box Making Machine With Dual Box Wrapping System | Box Length: | 105-600mm |
|---|---|---|---|
| Box Width: | 85-400mm | Box Height: | 7-120mm |
| Working Speed: | 3-45 Pcs/min | Condition: | New Model |
| Voltage: | 380V 3Phase | After-sales Service Provided: | Engineers Available |
| Edge Folding Size: | 10-89mm | ||
| Highlight: | Rigid Box manufacturing Machine,Perfume Box manufacturing Machine,45pcs/min Rigid Box Machine |
||
This model suitable for customer seeking for smart and high speed rigid box making machine. This is an ideal machine for rigid box manufacturer who has long and stable but changable orders.
It including the box corner pasting, paper gluing, box positioning, box wraping and pressing at one time. This machine has applied visual positioning for easy and high accurate positioning. Automatic setting in the forming station make the whole machine setting time reduce grealty.
Whole line setting time in 45-60 minutes. So that can meet different order quantity request. What`s more, it has a wide working range. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart setting machine.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
