27pcs/min Rigid Box Forming Machine LS-F6 Mobile Box Making Machine

LS-F6 Rigid Box Forming Machine Which Used For Making Gift Box, Cell Phone Box, Sweet Box, Candy Box

Applications:

LS-F6 Rigid Box Forming Machine is one of our top sell product, which use for ranges of rigid boxes making,such as shoes boxes, mobile phone boxes, gift boxes, luxury boxes and so on. It produces 20-30 pcs of box per minute, and also can handle special design boxes, such as the different height boxes & tucking into bottom etc. And this machine have been modified size to make Pandora ring boxes, welcome to contact us for more videos and details.

Gift Box Making Machine For Sweet Box And Rigid Paper Box is used for wrapping the glued paper in the pasted box. It can finished side wrapping, edge folding, tucking in and air pressing at one time, which is suitable for all kinds of rigid box wrapping, such as shoes boxes, gift boxes, cell phone boxes, perfume boxes etc.

3. Shut Down Procedure

1)Retract all cylinders and reset the main shaft to the origin,

2)Turn off the blower;

3)Press the power off button to turn off the power;

4)Turn off the gas source 1

Features:

It has applied Pneumatic and Compressor air to driving the machine running. It is an ideal equipment for customer which has different quantity orders. Especially the customer seeking for higher quality products.It has two edge folding model and four types tucking in model. The shortest time of one box finished is 1.7seconds. The max speed can reach 28 pcs/min to certain boxes.

Type	LS-F6
Max box size	L460*W380*H120mm
Min box size	L80*W65*H10mm
Motor power/voltage	2.5kw/220V
Air supply	10L/min 0.6Mpa
Working speed	≤30pcs/min
Machine dimension	L1220*W960*H2100mm
Weight of machine	920kg
