CE 898kg Rigid Box Forming Machine LS-F6 Custom Box Making Machine

LS-F6 Rigid Box Wrapping Machine For Gift Box, Cell Phone Box, Cosmetic Box

Applications:

LS-F6 Rigid Box Wrapping Machine For Gift Box, Cell Phone Box, Cosmetic Box, which use for ranges of rigid boxes making,such as shoes boxes, mobile phone boxes, gift boxes, luxury boxes and so on. It produces 20-30 pcs of box per minute, and also can handle special design boxes, such as the different height boxes & tucking into bottom etc. And this machine have been modified size to make Pandora ring boxes, welcome to contact us for more videos and details.

Gift Box Making Machine For Sweet Box And Rigid Paper Box is used for wrapping the glued paper in the pasted box. It can finished side wrapping, edge folding, tucking in and air pressing at one time, which is suitable for all kinds of rigid box wrapping, such as shoes boxes, gift boxes, cell phone boxes, perfume boxes etc.

Mold processing

Because the wooden mold is laser cut, there will be black edges and burrs after processing, so we must process the wooden mold after we get it. Generally, we will use sandpaper or a sanding machine to remove the burrs and polish it a little at the same time, so that when the wooden mold fits the box, it can meet the requirements. After sanding, the upper mold is covered with high temperature tape (1. Reduce the friction of the box in and out, 2. This tape is non-sticky to prevent glue from sticking to the mold when it is folded in); After the bottom mold is installed, a layer of foam is attached (to prevent the mold from scratching the box)

Features:

It has applied Pneumatic and Compressor air to driving the machine running. It is an ideal equipment for customer which has different quantity orders. Especially the customer seeking for higher quality products.It has two edge folding model and four types tucking in model. The shortest time of one box finished is 1.7seconds. The max speed can reach 28 pcs/min to certain boxes.

Type	LS-F6
Max box size	L460*W380*H120mm
Min box size	L80*W65*H10mm
Motor power/voltage	2.5kw/220V
Air supply	10L/min 0.6Mpa
Working speed	≤30pcs/min
Machine dimension	L1220*W960*H2100mm
Weight of machine	920kg













































Company introduction:



Longxingsheng Machinery Co.,Ltd is located in the famous manufacturing city - Dongguan City, Guandong province, China.

We are one of the leading & professional manufacturer of Automatic/Semi-automatic Rigid Box Making Machines & cardboard grooving machine for varies rigid box making, such as cardboard boxes, luxury boxes, jewelry boxes,calendar, gift boxes, sweet boxes, shoes boxes, watch boxes, mobile phone boxes, etc.



Our company has been established since 2006,we have our own independent R&D Department whichis led by Tsinghua University Doctor. Up to now, we have got more than 10 patents including practical patents, appearance patents & technology-based patents.With years experience of post press machinery's research,development,manufacturing and selling,our products are provided to everywhere of countries, especially in Europe,Asia,Mid-east and America.



We are much appreciated & treasure our customers' trust & support, and we will always keeping providing high quality products & good after-sales service to you !
