Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Shoe Wine Preium Box Making Machine With Visual Positioning | Box Length: | 93-600mm |
|---|---|---|---|
| Box Width: | 73-400mm | Box Height: | 15-100mm |
| Positioning Accuracy: | 0.11mm | Weight: | 4300KG |
| Condition: | New | Warranty: | 1 Year |
| Dimension(l*w*h): | 6600x4310x3000 Mm | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support |
| High Light: | Shoe Box Making Machine 0.11mm,Shoe Box Making Machine 73mm,Rigid Box Making Machine 400mm |
||
As the development of global market, the print and packing industries has increasing greatly. It have meet the situation that more and more orders and few experienced engineer of machine operation. It is the reason why we developing the LS-1246D, for high speed and intelligent setting.
It suitable for customer seeking for smart high speed rigid box making machine. This is an ideal machine for rigid box manufacturer who has long and stable but changable orders.
Whole line setting time in 45-60 minutes. So that can meet different order quantity request. What`s more, it has a wide working range. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart setting machine.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
