Product Details:
|
| Max Box Type: | L400*W300*H120mm | Min Box Type: | L70*W65*H15mm |
|---|---|---|---|
| Working Speed: | Up To 25 Pcs/min | Voltage: | 0.5kw/220v |
| Air Supply: | 10L/min 0.6MPa | Machine Dimension: | L1380*W1060*H1900mm |
| Machine Weight: | 400kg | ||
| High Light: | Automatic Box Pressing Machine,220v Rigid Box Pressing Machine |
||
Box pressing machine
1.In the production of the box of different heights, put the box into the operation table, adjust the height by screw rising device and fixed. It can save time and easy control the size of side of box.
2.There are thick paper (eg:200-350G gold and silver cards) anti rebound device options, the customer can choose the option item according to different box.
3.The machine adopt famous brand linear bearing, hard chrome plated shaft, the surface coated by the baking powder enamel printed etc.
This machine is ideal automatic high speed grooving machine which is widely applied on hardcover,setup box and gift box v grooving. It can promote the product’s quality, appearance and make products more high-end.
This product uses bubble extrusion on the side of the box. It can automatically press 5 surfaces, thus realizing high efficiency, high precision, high return and low cost. This machine is simple to operate, easy to debug, is the most ideal slotting equipment. Thank you for your choice and use.
| Type | LS-ATYP-5 |
| Max box type | L400*W300*H120mm |
| Min box type | L70*W65*H15mm |
| Working speed | Up to 25pcs/min |
| Voltage | 0.5kw/220v |
| Air supply | 10L/min 0.6MPa |
| Machine dimension | L1380*W1060*H1900mm |
| Machine weight | 400kg |
About our company
Dongguan Longxingjian Intelligent Equipment Co.,Ltd is located in the famousmanufacturing city - Dongguan City,China. Our former company name is Dongguan Longxingsheng machinery CO.,Ltd. We are the leader & professional manufacturer of Automatic/semi-auto rigid box maker which is for for making varies rigidbox ,such as cardboard boxes, luxury boxes, jewelry boxes,calendar, gift boxes, sweet boxes,shoes boxes, watch boxes, mobile phone boxes, high-end boxes and etc. Our company has been established since 2006.With years experience of machinery's development,manufacturing & selling,our products are with high quality & enjoy very good reputation in global market,especially in Europe,Asia,Mid-east and America. We are much appreciated & treasure our customers' trusting & supporting, and we will always keeping providing high quality products & good after-sales service to you.
Pre-sale service:
* Inquiry and consulting support.
* Sample testing support.
* Factory visit.
* Order confirmation
After-sale service:
* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* On-line technology support.
* Free machine parts replacement during warranty.
* Whole life of machine service.
Daily maintenance
Clean up the machine everyday as appropriate. When cleaning the machine,please use vacuum cleaner or clean rags. Apply some cleanser on the clean rags to remove the dirty spot and scrub the machine.
Machine maintenance personnel must have a professional level, maintenance personnel for equipment maintenance, must cut off all the power supply equipment.
Routine maintenance
Cleaning
Machine cleaning cycle should be once per shift (8 hours), can be arranged according to the actual situation.
When cleaning the outside of the machine, it is recommended to use a vacuum cleaner or a clean cloth; If there are dirty parts, you can use alcohol or odourless , non-foam solution of scale remover to drop on a clean cloth to wipe the equipment.
Periodic inspection
Before each shift starts up, check whether the air pressure gauge pressure meets the production requirements and whether the connecting part of the machine is loose, etc. Safety device spot check cycle is once a week.
Lubrication of components
Lubricate the bubble guide rod with lubricant every day.
