Automatic Smart Rigid Packaging Sweet Box Making Machine Cardboard Box Maker Phone Box Wrapping System
LS-1246B Autoamtic Packaging rigid box making machine is an suitable equipment for customer who has changable and intelligent orders. It including the box corner pasting, paper feeding and gluing, box positioning, box wraping and pressing at one time.
This equipment has applied visual positioning for easy and high accurate positioning. Automatic setting in the forming station make the whole machine setting time reduce grealty. Whole line setting time in 30-45 minutes. So that can meet different order quantity request.
What`s more, it has a wide working range. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart setting machine. The LS-1246B is best choice for rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
Specs of autoamtic smart rigid box making machine
| Type |
LS-1246B |
| Paper size(max) |
L800*W600mm |
| paper size(min) |
L135*W100mm |
| Max cardboard size |
L760*W560mm |
| Min cardboard size |
L120*W100mm |
| Box size(length) |
L100-600mm |
| Box size(width) |
W60-400mm |
| Box size(height) |
H15-120mm |
| Paper thickness |
80-350g/m2 |
| Cardboard thickness |
0.8-3mm |
| Edge folding size |
10-90mm |
| Turn in depth |
15-80mm |
| Working speed |
15-25 pcs/min |
| Motor power |
13kw/380v 3phase |
| Heating power |
8kw |
| Air pressure |
40L/min 0.8MPa |
| Weight of machine |
3800kg |
| Machine dimension |
L6600*W3800*H3000mm |
Machine advantages
Quickly job setting
No need to change tuck in blade
No need to move camera for size changing, quick job changing
Make high-end boxes
Can use the carton paper to wrap the inner box
Can make big size box, such as 600*400mm, and the height can reach 120mm
Storage(memory) function for sizes setting
Suitable for changeable orders
Such as 10,000 pcs for one order
Main features:
1. Automatic setting function.
2. Storage function for the positioning part, easy to adjustment
3. Pick up box system, can avoid to scraping cover paper, suitable for making high-end boxes
4. YAMAHA Robotic arm
5. Double Germany cameras (1000 pixels)
Price vary with raw material cost, please contact our sales for latest prices.
Machine setting time: Short in 45 minutes
Intelligent setting page
Machine parts
