Product Details:
|
| Products Name: | Automatic Smart Packaging Rigid Book-Type Gift Box Making Machine Cardboard Box Maker Phone Box Wrapping System | Max Paper Size: | L800*W600mm |
|---|---|---|---|
| Min Paper Size: | L135*W100mm | Working Speed: | 15-25 Pcs/min |
| After Sale Service: | Engineer Available | Warranty: | One Years |
| Material: | Steel And Air Cylinder | Machine Weight: | 3800Kg |
| Highlight: | Book Type Gift Box Making Machine,15pcs/Min Gift Box Making Machine,Book Type Corrugated Box Manufacturing Plant |
||
stment rocker" to adjust the distance between the "baffles". The distance between the "baffles" should be close to the front of the tissue paper. Loosen the "limit lever adjustment handle" to adjust the distance of the "limit lever".
The distance between the "limit levers" should be close to both sides of the tissue paper. The main purpose of these two adjustments is to limit the position of the tissue paper so that it is fixed in the same position without changing.
"Paper guide adjustment" can be adjusted according to the size of the surface paper. Its main function is to guide the surface paper that has entered the rubber roller to prevent it from folding in half.
| Type | LS-1246B |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-25 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 3800kg |
| Machine dimension | L6600*W3800*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
