Product Details:
|
| Products Name: | Automatic Smart Packaging Rigid Drawer Box Making Machine Cardboard Box Maker Phone Box Wrapping System | Max Paper Size: | L800*W600mm |
|---|---|---|---|
| Min Paper Size: | L135*W100mm | Box Length: | 80-600mm |
| Box Width: | 65-400mm | Working Speed: | 15-25 Pcs/min |
| Edge Folding Size: | 10-90mm | Turn In Depth: | 15-80mm |
When the cover paper is glued, the drum must be turned on and then the glue is drawn. The glue will flow out from the glue outlet above the drum. First adjust the "paper roller" and the paper feed roller in sequence according to the thickness of the tissue paper.
Then adjust the position of the scraper according to the size of the tissue paper. Generally, the scraper is at least one in the middle of the tissue and one on each side. If the number of scrapers is too small, the tissue may not be completely scraped off.
The LS-1246B is best choice for rigid box, gift box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
| Type | LS-1246B |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-25 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 3800kg |
| Machine dimension | L6600*W3800*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
