Product Details:
|
| Products Name: | Automatic Smart Packaging Rigid Tea Mobile Box Making Machine Cardboard Box Maker Phone Box Wrapping System | Max Cardboard Size: | L760*W560mm |
|---|---|---|---|
| Min Cardboard Size: | L120*W100mm | Box Length: | 80-600mm |
| Box Width: | 65-400mm | Box Height: | 15-120mm |
| Working Speed: | 15-25 Pcs/min | Paper Thickness: | 80-340gsm |
| Cardboard Thickness: | 1-4mm | ||
| Highlight: | Smart Automatic Rigid Box Making Machine,25 pcs/min Automatic Rigid Box Making Machine,Smart Automatic Corrugation Plant |
||
Cameras:Located on the top of the conveyor belt, the image of the conveying paper is taken, and the robot takes the box and the positioning is controlled by the system.
Robotic arm:Grab the box blank and accurately position it on the cover paper.
LED light:Illuminate the surface paper conveyor belt to separate the color of the surface paper from the conveyor belt and help the camera to take pictures and identify.
Box guide position:Guide the box embryo with the corners to the manipulator to take the box, so that the manipulator is positioned accurately.
Box conveyor belt:Convey the finished corner pasting box to the positioning machine.
| Type | LS-1246B |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-25 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 3800kg |
| Machine dimension | L6600*W3800*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
