Servo Motor Feeding Fully Automatic Box Forming Machine 35pcs/min

Name: Servo Motor Feeding Fully Automatic Box Forming Machine 35pcs/min
Brand: Dongguan Longxingjian Intelligent Equipment Co., Ltd.
SKU: LS-300B
Price: 100,000.00 USD
Availability: InStock

All Products

Rigid Box Making Machine
(146)

Packaging Box Making Machine
(148)

Rigid Box Forming Machine
(39)

Board Grooving Machine
(88)

Rigid Box Wrapping Machine
(45)

Gift Box Making Machine
(24)

Box Corner Pasting Machine
(26)

V Groove Cutter Machine
(5)

Paper Gluing Machine
(18)

Automatic Case Making Machine
(13)

Hot Melt Packaging Tape
(14)

Box Pressing Machine
(10)

Positioning Machine
(28)

Best Products

Rigid Drawer Hardboard Gift Box Making Machine Box Width 76mm-400mm

Rigid Lid Base Sweet Box Cutting Machine 0.16mm Visual Positioning

Rigid Jewelry Cigarate Gift Box Making Machine Box Length 102mm-600mm

Certification

I'm Online Chat Now

Servo Motor Feeding Fully Automatic Box Forming Machine 35pcs/min

Large Image : Servo Motor Feeding Fully Automatic Box Forming Machine 35pcs/min

Product Details:

Place of Origin:	China
Brand Name:	Longxingsheng
Certification:	CE, ISO9000
Model Number:	LS-300B

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	wooden case
Delivery Time:	30-60 days
Supply Ability:	10-20 set per month

Contact Now

Servo Motor Feeding Fully Automatic Box Forming Machine 35pcs/min

Description

Type::

Multi-Function Packaging Machine

Applicable Industries::

Packaging Factory

Application::

Machinery&Hardware

Packaging Material::

Paper, Plastic, Wood

Highlight:

Box Forming Machine 35pcs/min

Servo Motor Feeding Box Forming Machine

Box Making Machine 35pcs/min

Fully Automatic Box Forming Machine For Cell Phone Box Making

Main features

High Speed, Suitable for big orders. especially for the orders which are more than 50,000 pcs at one time for the same size,
because one line can make around 14000 pcs/ day. Better service for long-term and stable orders2. Dual-forming stations, box forming has divided into two forming stations, increasing whole line working speed.
Pick up box system, can avoid to scraping cover paper, suitable for making high-end boxes
YAMAHA Robotic arm
Double Germany cameras (1000 pixels) 6. Mitsubishi servo motor 7. Panasonic PLC 8. Anti-leaking gluing system 9. Servo motor feeding system 10. Storage function for the positioning part, easy to adjustment
Whole machine require working in stable working environment. Such as air contioner room.


Products Description

High Speed Performance

**Specs of autoamtic Fully Automatic Rigid box making machine**
Type	LS-300B
Paper size(max)	L800*W600mm
paper size(min)	L135*W100mm
Max cardboard size	L760*W560mm
Min cardboard size	L120*W100mm
Box size(length)	L80-400mm
Box size(width)	W60-300mm
Box size(height)	H15-100mm
Paper thickness	80-350g/m2
Cardboard thickness	0.8-3mm
Edge folding size	10-90mm
Turn in depth	15-80mm
Working speed	15-35 pcs/min
Motor power	14kw/380v 3phase
Heating power	8kw
Air pressure	40L/min 0.8MPa
Weight of machine	3750kg
Machine dimension	L6600W3800H3000mm

Company Profile

Dongguan Longxingjian Intelligent Equipment Co.,Ltd


We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd. We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery`s research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.
