LS-300D Intelligent Setting Rigid Box Making Machine Ice Cream Candy Small Box Packing Machine

Large Image : LS-300D Intelligent Setting Rigid Box Making Machine Ice Cream Candy Small Box Packing Machine

Product Details:

Place of Origin:	China
Brand Name:	Longxingsheng
Certification:	CE/ISO-9001
Model Number:	LS-300D

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	with film, paper and wooden crates
Delivery Time:	7-30 workdays
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	30 Sets per month

Contact Now

LS-300D Intelligent Setting Rigid Box Making Machine Ice Cream Candy Small Box Packing Machine

Description

Type::	Boxing Machine	Machinery Test Report::	Provided
Condition::	New	Packaging Type::	Case
Automatic Grade::	Automatic	Warranty::	1 Year
Highlight:	PLC Small Box Packing Machine , 1000pixels Small Box Packing Machine , 40Pcs/min Rigid Box Making Machine

Products Description

Application of automatic high speed smart rigid box making machine

Quickly job setting

No need to change air pressing plate
No need to change tuck in blade
No need to move camera for size changing, quick job changing
Storage(memory) function for sizes setting

Make high-end boxes

Special pick up and wrapping system
Can use the carton paper to wrap the inner box
Can make smallest size box, such as 50*50*12mm

Suitable for changeable orders

Such as 1,000 pcs for one order

Main features:

1. Automatic setting function.

2. Storage function for the positioning part, easy to adjustment

3. Pick up box system, can avoid to scraping cover paper, suitable for making high-end boxes

4. YAMAHA Robotic arm

5. Double Germany cameras (1000 pixels)
6. Mitsubishi servo motor
7. Panasonic PLC
8. Anti-leaking gluing system
9. Servo motor feeding system

10. Double forming part. High Speed.

11. Whole machine require working in stable working environment. Such as air conditioner room.

Price vary with raw material cost, please contact our sales for latest prices.


Automatic setting function

LS-300D/1246D Automatic smart rigid box making machine
Machine model	LS-300D	LS-1246D
Paper size(max)	L550*W450mm	L800*W600mm
paper size (min)	L120*W70mm	L150*W100mm
Box size(length )	L 50-350mm	L 80-600mm
Box size(width)	W 50-250mm	W 65-400mm
Box size(height)	H 12-100mm	H 15-120mm
Max board size	L550*W400mm	L760*W560mm
Min board size	L80*W70	L120*W100
Paper thickness	80-350g/㎡	80-350g/㎡
Working speed	15-40 pcs/min	15-45pcs/min
Positioning accuracy	±0.1 mm	±0.1 mm
Motor power	16kw/380v 3 phase	14kw/380v 3 phase
Heating power	8 kw	8 kw
Air pressure	40L/min 0.8Mpa	40L/min 0.8Mpa
Weight of machine	3600kg	5000kg
Machine dimension	L6400W4000H3000mm	L7600W3800H3000mm
