Product Details:
|
| Product Name: | Rigid Box Maker For Luxury Boxes, Rigid Paper Box And Cell Phone Boxes | Machine Dimension: | L1221*W963*H2101mm |
|---|---|---|---|
| Working Speed: | ＜30pcs/min | Warranty: | 1 Year |
| Power: | 2.5kw | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Highlight: | Rigid Box Maker 2.5kw,Mobile Rigid Box Maker,30pcs/Min Mobile Box Making Machine |
||
Rigid Box Maker For Luxury Boxes, Rigid Paper Box And Cell Phone Boxes
Applications:
LS-F6 is forming maker for rigid box .Not only making small box but also suitable big size box .
Mode Selection
A:Edge Mode: 4 modes
Fold the four sides at the same time: Fold in the four sideboards at the same time, which is suitable for the box shape that does not fold to the bottom.
Fold the opposite sides at the same time: first fold in the ①③ side and then ②④ fold in the side, suitable for folding to the bottom box shape.
Single-sided folding: Fold in in order of ①③②④, suitable for a smaller square box folding to the bottom.
Fold one side first and then side-to-side: Fold first ① then ③ and then ②④ at the same time, suitable for ①③ with longer side fold in length, ②④ with shorter side fold.
Every page have two languages, we can change Chinese to English easily and also provide third language according to customers' demand.
Features:
It has applied Pneumatic and Compressor air to driving the machine running. It is an ideal equipment for customer which has different quantity orders. Especially the customer seeking for higher quality products.It has two edge folding model and four types tucking in model. The shortest time of one box finished is 1.7seconds. The max speed can reach 28 pcs/min to certain boxes.
| Type | LS-F6 |
| Max box size | L460*W380*H120mm |
| Min box size | L80*W65*H10mm |
| Motor power/voltage | 2.5kw/220V |
| Air supply | 10L/min 0.6Mpa |
| Working speed | ≤30pcs/min |
| Machine dimension | L1220*W960*H2100mm |
| Weight of machine | 920kg |
Company introduction:
Longxingsheng Machinery Co.,Ltd is located in the famous manufacturing city - Dongguan City, Guandong province, China.
We are one of the leading & professional manufacturer of Automatic/Semi-automatic Rigid Box Making Machines & cardboard grooving machine for varies rigid box making, such as cardboard boxes, luxury boxes, jewelry boxes,calendar, gift boxes, sweet boxes, shoes boxes, watch boxes, mobile phone boxes, etc.
1. Is the packaging firm? ----sure! All of our export packaging is in strong wooden boxes, which meet export packaging standards.
2. How about the after-sales service process? ----When there is a problem with your machine, just contact your salesman, we will solve your problem as soon as possible.
3. Can your engineer come to us to install the machine and deal with the problem? ---Yes, we can. And the installation and training for 7 working days are free, you only need to pay for air tickets and accommodation for our engineers.
4. Are you a manufacturer? ----Yes, we are a manufacturer with more than 12 years professional experience. Welcome the sole agent in Europe/Asia/Africa/America to join us.
5. What is the MOQ? ----1 set, we do business step by step with high quality products and excellent service.
6. Do you inspect the finished products? ----Yes, every step of producing products will be inspected by our QC department, and the running inspection video will be sent to you for your verification before shipment.
7. What is the payment terms? ---FOB/CIF terms, T/T 30% prepaid, 70% balance before shipment. (negotiable)
If you have any inquiry, please don't hesitate to contact us. We will reply you at the first time as we can.
