Product Details:
|
| Product Name: | Automatic Paper & Box Positioning Box Packaging Machine For Making Gift Box & Cellphone Box | Type: | Rigid Box Positionning Packaging Machine |
|---|---|---|---|
| Colour: | White | Working Speed: | 15-40pcs/min |
| Warranty: | 1 Year | Automatic Grade: | Automatic |
| Application: | Positioning Rigid Box/hard Cover/plastic Case | Dimension(L*W*H):: | L5980*W3180*H2100 |
| Weight Of Machine: | 1850kg | Certification: | CE, ISO |
| Highlight: | 40pcs/min Box Packaging Machine,ISO9001 Box Packaging Machine,15pcs/min Packaging Box Making Machine |
||
Automatic Paper & Box Positioning Box Packaging Machine For Making Gift Box & Cellphone Box
Introduction:
LS-450plus Visual box positioning machine is an automatic production equipment integrating gluing and positioning
This machine mainly feature is positioning the rigid box & plastic box .
Paper feeding table:Paper can be placed on the table and separated by a feeder. When the paper is reduced, the table will automatically rise to the paper suction position. When reloading paper, the table needs to be lowered manually, and the table can be raised or lowered by the side button.
Feeder feeding paper:Neatly stacked sheets of paper are fed into the gluing mechanism separately.
Gluing system:The paper feeder feeds the paper into the roller. After the roller works, the glue is evenly coated on the surface of the paper. The scraper separates the surface paper from the roller, and the paper is transported to the positioning position by the conveyor belt.
Press box: Position the finished face paper and reinforce the bottom of the box.
Paper roller:The paper that has not been positioned with the box or the residual paper on the conveyor belt is recycled to reduce the probability of secondary scrapping.
Glue tank:After the glue is melted, it is sent to the glue passing mechanism, and the glue can be heated for a specific time.
6. Panasonic Servo motor ensure the stable working.
Two 10-megapixel cameras can capture tissues in a wide range to improve accuracy
Can handle different colors of cover paper, such as black, white, red, green, blue etc.
Local Language Operation System:Local language operation system avialable, including Korea, Vietness, Spanish, Russian,Turkish etc.
| Type | LS-450B |
| Paper size (Max) | L800*W600mm |
| Paper size (Min) | L135*W100mm |
| Max box size |
L430*W350*H100mm |
| Min box size | L80*W65*H15mm |
| Paper thickness | 100-350g/㎡ |
| Paper stacking height | 280mm |
| Motor power / voltage | 6.8kw/380v, 3 phase |
| Heating power | 8kw/380v, 3 phase |
| Air supply | 10L/min 0.6Mpa |
| Working speed | 15-35 sheets/min |
| Machine dimension | L5990*W3180*H2100mm |
| Weight of machine | 2100kg |
Company profile:
Dongguan Longxingjian Intelligent Equipment Co.,Ltd is located in world manufacturer city----Dongguan City, Guangdong Province.
Grooving machine series and rigid box forming series are our main products, we have provide more rigid box making solutions for thousands of companies and gain much good feedback.
We hold "professional, focus, customer first" as our operating principle, and try our best to "Simply box making". Insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing & Packaging industry.
Our online-service:
We will create a Wechat group to provide online service, including one or two engineer inside. If machine has problem during the warranty time which is not caused by wrong operation, buyer shall send video or pictures so that seller can figure out the exact problem. What‘s more, seller shall give technical support to buyer.
FAQ
1. Does the packing strong?----Yes, of course! All of our export packing is with strong wooden case,all are confirm to export packing standard.
2. How about after-sales service process?----When your machine has problem, just contact your sales and we will solve your problem ASAP.
3. Can your engineer come to us for installing the machine & handle problems?---Yes,we can.And it is free-cost for the installing & training for 7 work days,you just need to pay for the air tickets & accommodation for our engineer.
4. Are you a manufacturer?----Yes, we are a manufacturer with over 12 years professional experience .Welcome the exclusive agents in Europe/Asia/Africa/America to join us.
5. What is the minimum quantity for order?----1 set, we done business step by step with high quality products and excellent services.
6. Do you inspect the finished products?----Yes, each step of production products will be inspection by our QC department and the running inspection video will be sent to to you for your verification before shipping.
7. What’s the payment term?---FOB/CIF terms,payment by T/T 30% in advance,70% balance before shipping.(It is negotiable)
