Product Details:
|
| Products Name: | Automatic Smart Packaging Shoe Clothing Box Making Machine Cardboard Box Maker Phone Box Wrapping System | Box Length: | 80-540mm |
|---|---|---|---|
| Box Width: | 65-380mm | Box Height: | 12-120mm |
| Working Speed: | 0-25 Pcs/min |
1246B is designed based on our 12 years’ experience of rigid box machine manufacturing. Compared to other models on the market, 1246B has higher speed and biggest size range up to 400*600*120mm. Under stable performance it can produce 25 boxes per min.It’s automatic setting feature greatly simplify box making for our customers.The LS-1246B is best choice for rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
LS-1246B Automatic smart rigid box making machine is an ideal machine for customer who has changable orders. It including the box corner pasting, paper feeding&gluing, box feeding&positioning, box wraping and air pressing at one time.
Cardboard feeding structure: Place the cardboard on the table, the cardboard will be sucked and separated by the vacuum nozzle, and then transferred to the center of the spindle through the roller belt to wait for the spindle to form. When loading paper, you can use the button on the left to raise or lower the platen.
Corner pasting : the tape is hot-melted and pasted by the heating copper head. The main shaft mold presses the cardboard into the limit plate and then the box is folded by the copper head. Return the material.
Box take-out structure: Take down the corner-attached box embryo and make it stably fall on the box embryo conveyor belt.
The LS-1246B is best choice for rigid box, gift box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
| Type | LS-1246B |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-25 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 3800kg |
| Machine dimension | L6600*W3800*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
