Product Details:
|
| Products Name: | Pneumatic Rigid Box Cardboard Groove Cutting Machine , Paper Card V Grooving Machine | Working Speed: | 45m/min |
|---|---|---|---|
| Max Size: | 1000*800 Mm | Min Size: | 140*120mm |
| Carton Paper Thickness: | 500-800g/m² | Cardboard Thickness: | 0.8 To 4 Mm |
| Machine Dimension: | L2000*W1520*H1400mm | Machine Weight: | 1100Kg |
High Accuracy Rigid Box Cardboard Groove Cutting Machine For Paper Cover Book Cover
LS-1200B automatic cardboard slotting machine is used for slotting cardboard V-groove,suitable rigid box makingand cardboard grooving factory . 80-140 degree V groove can be opened. It can slot 8 slots at a time (depending on cardboard size). The working speed is 40m/min, about 100-200 pieces/min
| Product name | Automatic Box Package Cover Paper Grooving Machine |
|
Machine model
|
LS-1200B
|
|
Quantity of groove at a time
|
8 slots
|
|
Working speed
|
40m/min(100-200pcs/min)
|
|
Cardboard size
|
140*120-1000*600mm
|
|
Cardboard thickness
|
0.8-4mm
|
|
Motor power
|
2Kw/380v
|
|
Machine dimension
|
L2050*W1320*H1350mm
|
|
Machine weight
|
1250kg
|
V-groove cutting: V-groove can be created with this specialized cardboard V-groove cutting machine. The cutting angle of the V-groove is adjustable from 80 degrees to 140 degrees, providing flexibility for bevel customization.
Simultaneous slots: LS-1200B can slot 8 slots at the same time (depending on the size of the cardboard). This feature increases productivity and allows you to efficiently process multiple slots per operation.
Working speed: The machine works at a high working speed of 40 meters per minute. This equates to approximately 100 to 200 pieces per minute, allowing for fast and efficient production.
Material Compatibility: LS-1200B is designed for grooving various types of materials such as grayboard, cardboard, and density board. This versatility allows for the processing of a wide range of applications and materials.
Cardboard size range: The maximum size of slotted cardboard that the machine can accommodate is 1000mm x 600mm. The minimum size for slotted cardboard is 140mm x 120mm. This size range provides flexibility for different board sizes.
LS-1200B especially focuses on V-groove cutting, providing high-speed, high precision and efficient grooving capabilities. It is suitable for applications that require V-groove machining as it can be made with a variety of materials and sizes.
In fact, the high-quality packaging makes the LS-1200B ideal for a variety of applications. Precise V-groove cutting capabilities make it suitable for creating all types of boxes and packaging solutions. Specific applications where the LS-1200B can be used include:
Gift Boxes: This machine creates precise V-grooves for gift boxes, improving their aesthetics and structural integrity.
Jewelry boxes: Jewelry boxes often require intricate designs and precise grooves, and the LS-1200B effectively meets these requirements.
Watch packaging: This machine can make grooves for watch packaging, ensuring safety and beautiful appearance.
Mobile phone boxes: Mobile phone boxes often have specific dimensions that require precise slots, and the LS-1200B can achieve this.
Wine box: This machine is suitable for wine box grooves, providing you with a professional and elegant packaging solution.
Storage Box: Whether for home or commercial use, LS-1200B can create a recess for a sturdy and functional storage box.
Shirt and shoe boxes: This machine can create grooves for packing shirt and shoe boxes, giving them a neat and organized structure.
Cosmetic and toiletry boxes: LS-1200B can be used to create recesses in cosmetic and toiletry boxes, ensuring high quality and well-designed packaging solutions.
Biscuit and cake boxes: This machine can make grooves for biscuit and cake boxes, contributing to their structural stability and visual appeal.
Totally 8 blade seat which is able to installed blade holder.
Key Features:
1.Superior Precision: Our V grooving machine ensures precise and consistent grooves, allowing for seamless folding and assembly of rigid boxes. Say goodbye to uneven cuts and imperfect folds.
2.Versatile Applications: With its adjustable parameters, our machine accommodates various cardboard thicknesses and grooving depths, providing flexibility for a wide range of box sizes and styles. Whether you're producing jewelry boxes, gift boxes, or cosmetic packaging, this machine has you covered.
3.Efficiency and Speed: Experience a significant boost in productivity with our automatic grooving machine. Its high-speed operation and automated processes streamline your workflow, reducing production time and increasing output.
Dongguan Longxingjian Intelligent Equipment Co.,Ltd
We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd.
We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery's research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.
We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.
Our advantages
Certificates: ISO9001-2008, Quality management system, CE certificate.
Mission & Vision: Provide smart modular for packaging.
Products scope: Automatic rigid box making machine. V grooving machine. Visual positioning machine. Rigid box former. Corner pasting machine. Gluing machine and other machinery.
Market positioning: Middle and high-end market
Our advantages
: ISO9001-2008, Quality management system, CE certificate.
: Provide smart modular for packaging.
: Automatic rigid box making machine. V grooving machine. Visual positioning machine. Rigid box former. Corner pasting machine. Gluing machine and other machinery.
: Middle and high-end market
Installation Services are available with all Our machines. We dispatch technician to customer's factory for installation and
preoperation of machines. ( Customers only need to pay the airfare and hotel )
2.Training Service
Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines.
