Product Details:
|
| Paper Size(max): | L800*W600mm | Paper Size (min): | L180*W100mm |
|---|---|---|---|
| Box Size(max): | L600*W400*H120mm | Box Size(min): | L80*W60*H20mm |
| Max Board Size: | L700*W600mm | Min Board Size: | L100*W80 |
| Paper Thickness: | 100-200g/㎡ | Working Speed: | ≤26 Sheets/min |
| Positioning Accuracy: | ≤0.3 Mm | Motor Power: | 14kw/380v 3 Phase |
| Heating Power: | 4 Kw | Air Pressure: | 20L/min 0.8Mpa |
The packaging industry has evolved greatly over the years, and the demand for high-quality packaging solutions has increased significantly. The introduction of automated packaging machines has made it easier to produce packaging products in large quantities while maintaining high levels of quality. One such machine is the multifunctional fully automatic rigid box making machine, which has gained popularity among customers worldwide. In this article, we will explore the features and benefits of the Longxing Sheng intelligent rigid box making machine.
LS-1246B is an automatic rigid box making machine, this machine maxspeed up to 20-25 pcs/min, max box size rang up to: 400*600*120mm, min size is: 100*60*15mm.
This model have double 10 mega pixel cameras, when make difference size box, this camera dont need to move small size to big size.
| Type | LS-1246B |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-25 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 3800kg |
| Machine dimension | L6600*W3800*H3000mm |
1.Applied Mitsubishi servo motor to control all line movement, system running efficiency and stable
2. Applied servo motor and cylinder in air pressing with better efficiency
3. Fast-size changing which is controlled by servo motor
4. Box picking up system, avoid paper scratching
5. Robotic arm from eorking accuracy is 0.1mm
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
