Product Details:
|
| Products Name: | Automatic Smart Rigid Match Watch Box Making Machine With Dual Box Wrapping System | Max Cardboard Size: | L760*W560mm |
|---|---|---|---|
| Min Cardboard Size: | L120*W100mm | Box Length: | 106-600mm |
| Box Width: | 66-380mm | Box Height: | 15-110mm |
| Working Speed: | 5-43 Pcs/min | Condition: | New |
| Voltage: | 380V 3 Phase | After-sales Service Provided: | Engineers Available |
| Highlight: | Smart Watch Rigid Box Making Machine,Rigid Box Making Machine Dual Box Wrapping,380mm gift box making machine |
||
This is an ideal machine for rigid box manufacturer who has long and stable but changable orders. Such as, need to change size in 10K, It suitable for customer seeking for intelligent high speed rigid box making machine.
It including the box corner pasting, paper gluing, box positioning, box wraping and pressing at one time. This machine has applied visual positioning for easy and high accurate positioning. Automatic setting in the forming station make the whole machine setting time reduce grealty.
Whole line setting time in 45-60 minutes. So that can meet different order quantity request. What`s more, it has a wide working range. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart setting machine.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
