Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Top And Bottom Box Making Machine With Visual Positioning | Box Length: | 99-600mm |
|---|---|---|---|
| Box Width: | 89-400mm | Box Height: | 29-120mm |
| Edge Folding Size: | 11-90mm | Turn In Depth: | 15-99mm |
| Positioning Accuracy: | 0.21mm | Cardboard Feeding Way: | Table Feeding |
| Paper Feeding Way: | Servo Motor Sunction Feeding | ||
| Highlight: | Rigid Top automated box making machine,automated box making machine 89mm,sweet box making machine 400mm |
||
LS-1246D are the latest rigid box making machine on the market for high speed production.
The LS-1246D has a good appearance in the rigid box production with high speed. To ensure the best appearance of box, it will equipped with an automatic air pressing machine to combine with its high speed. It is good helper to customer, it can running in high speed 25-45 pcs/min, middle speed 15-25 pcs/min.
As dual forming station can only running one to save energy. It also has degined for a wide range box production with intelligent setting. The max box length is 600mm, max width is 400mm, Max height is 120mm. Whole line has applied the visual positioning technology in rigid box making. Ensure its high working speed and accuracy, Whole working speed can be adjusted in one button. The intelligent setting has ensured it can change new size in the shortest time.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
