Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Cover And Tray Box Making Machine With Visual Positioning | Box Length: | 98-600mm |
|---|---|---|---|
| Box Width: | 88-400mm | Box Height: | 15-111mm |
| Edge Folding Size: | 10-75mm | Turn In Depth: | 16-80mm |
| Positioning Accuracy: | 0.2mm | Tape: | Plastic/paper Tape |
| Glue: | Animal Glue And White Glue | ||
| Highlight: | Rigid Box Making Machine 0.2mm,Rigid Box Making Machine Visual Positioning,0.2mm paper box making machine |
||
With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.
Automatic setting in the forming station make the whole machine setting time reduce grealty. This whole line including the box corner pasting, paper gluing, box positioning, dual box forming station and air pressing at one time. This machine has applied visual positioning for easy and high accurate positioning.
Whole line setting time in 45-60 minutes. So that can meet different order quantity request. What`s more, it has a wide working range. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart setting machine.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
