Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Lid And Base Box Making Machine With Visual Positioning | Box Length: | 97-600mm |
|---|---|---|---|
| Box Width: | 87-400mm | Box Height: | 27-120mm |
| Edge Folding Size: | 10-60mm | Turn In Depth: | 15-60mm |
| Positioning Accuracy: | 0.15mm | Tape: | Plastic/paper/Kraft Tape |
| Glue: | Animal Glue And White Glue | ||
| Highlight: | Rigid Lid Base packing box making machine,packing box making machine 0.15mm,industrial box making machine 0.15mm |
||
LS-1246D is an upgrade model of LS-300A, as LS-300A has a high speed in 30 pcs/min. But the disadvantage is setting not smart. As manual setting will required around 90-120 minutes. But the LS-1246D has the setting time in 45-60 minutes.
With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.
The max box length is 600mm, max width is 400mm, Max height is 120mm. Whole line has applied the visual positioning technology in rigid box making. Ensure its high working speed and accuracy, Whole working speed can be adjusted in one button. The intelligent setting has ensured it can change new size in the shortest time.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
