Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Shoe Skirt Preium Box Making Machine With Visual Positioning | Box Length: | 94-600mm |
|---|---|---|---|
| Box Width: | 74-400mm | Box Height: | 24-120mm |
| Positioning Accuracy: | 0.13mm | Glue: | Animal Glue And White Glue |
| Glue Tank: | Hot And Cold Tank Separately | Weight: | 4300KG |
| Condition: | New | Warranty: | 1 Year |
| Highlight: | Shoe Clothing Rigid Box Making Machine,Rigid Box Making Machine 74mm,400mm hard box making machine |
||
Why we developing the LS-1246D, for high speed and intelligent setting. As increasing of rigid box market, it have meet the situation that more and more orders and few experienced engineer of machine operating.
With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.
The LS-1246D has a good appearance in the rigid box production with high speed. Ensure its high working speed and accuracy, Whole working speed can be adjusted in one button. The intelligent setting has ensured it can change new size in the shortest time.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
