Automatic Smart High Speed Rigid Sweet Food Preium Box Making Machine With Visual Positioning
With the development of technology, we have applied the lastest technology, double camera, robotic arm visual positioning, automatic box setting. As increasing of rigid box market, it have meet the situation that more and more orders and few experienced engineer of machine operating. It is the reason why we developing the LS-1246D, for high speed and intelligent setting.
With the developing of print and packing production, more customer are seeking for an automatic rigid box making machine with higher speed and intelligent setting. So that the workers can focus on the rigid box quality production not in quantity.
The LS-1246D is best choice machine for rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
Specs of autoamtic smart rigid box making machine
| Type |
LS-1246D |
| Paper size(max) |
L800*W600mm |
| paper size(min) |
L135*W100mm |
| Max cardboard size |
L760*W560mm |
| Min cardboard size |
L120*W100mm |
| Box size(length) |
L100-600mm |
| Box size(width) |
W60-400mm |
| Box size(height) |
H15-120mm |
| Paper thickness |
80-350g/m2 |
| Cardboard thickness |
0.8-3mm |
| Edge folding size |
10-90mm |
| Turn in depth |
15-80mm |
| Working speed |
15-45 pcs/min |
| Motor power |
13kw/380v 3phase |
| Heating power |
8kw |
| Air pressure |
40L/min 0.8MPa |
| Weight of machine |
4300kg |
| Machine dimension |
L6600*W4200*H3000mm |
Machine advantages
Quickly job setting
Without change air pressing plate
Without change tuck in blade
Fixed camera for size changing, quick job changing
Make high-end boxes
Special pick up and wrapping system
Can make big size box, such as 600*400mm, and the height can reach 120mm
Storage(memory) function for sizes setting
Suitable for changeable orders
Such as 10,000 pcs for one order
Main features:
1. Automatic setting function.
2. Storage function for the positioning part, easy to adjustment
3. Robotic arm (Yamaha, Mitsubishi, Delta)
4. Double Germany cameras (1000 pixels)
5. Mitsubishi servo motor
6. Panasonic PLC
Price vary with raw material cost, please contact our sales for latest prices.
Machine setting time: Short in 45 minutes
Intelligent setting page
Machine parts
About our company
Dongguan Longxingjian Intellighent Equipment Co.,Ltd is located in the famousmanufacturing city - Dongguan City,China. Our former company name is Dongguan Longxingsheng machinery CO.,Ltd. We are the leader & professional manufacturer of Automatic/semi-auto rigid box maker which is for for making varies rigidbox ,such as cardboard boxes, luxury boxes, jewelry boxes,calendar, gift boxes, sweet boxes,shoes boxes, watch boxes, mobile phone boxes, high-end boxes and etc. Our company has been established since 2006.With years experience of machinery's development,manufacturing & selling,our products are with high quality & enjoy very good reputation in global market,especially in Europe,Asia,Mid-east and America. We are much appreciated & treasure our customers' trusting & supporting, and we will always keeping providing high quality products & good after-sales service to you.
Our advantages
Certificates: ISO9001-2008, Quality management system, CE certificate.
Mission & Vision: Provide smart modular for packaging.
Products scope: Automatic rigid box making machine. V grooving machine. Visual positioning machine. Rigid box former. Corner pasting machine. Gluing machine and other machinery.
Market positioning: Middle and high-end market
Major market: America, Europe, Asia, Mid-east.
FAQ
Q: How could I pay?
A1: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q2: What is your packing way? Can I have the customized package?
A2: We have the standard export package. For more details about the customized package, please contact us.
Q3: Are you a factory or a trading company?
A3: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
