Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Sweet Match Preium Box Making Machine With Visual Positioning | Box Length: | 87-600mm |
|---|---|---|---|
| Box Width: | 70-400mm | Box Height: | 18-110mm |
| Positioning Accuracy: | 0.06mm | Weight: | 4200KG |
| Warranty: | 1 Year | Paper Thickness: | 80-330gsm |
| Cardboard Thickness: | 1.1-4mm | ||
| High Light: | Sweet packaging box manufacturing machine,packaging box manufacturing machine 0.06mm,Sweet Box making machine 0.06mm |
||
We have applied the lastest technology, double camera, robotic arm visual positioning, automatic box setting. As increasing of rigid box market, it have meet the situation that more and more orders and few experienced engineer of machine operating. It is the reason why we developing the LS-1246D, for high speed and intelligent setting.
With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.
It suitable for customer seeking for smart high speed rigid box making machine. This is an ideal machine for rigid box manufacturer who has long and stable but changable orders.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
