Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Candy Window Preium Box Making Machine With Visual Positioning | Box Length: | 83-600mm |
|---|---|---|---|
| Box Width: | 68-400mm | Box Height: | 17-120mm |
| Positioning Accuracy: | 0.001mm | Paper Thickness: | 82-350gsm |
| Cardboard Thickness: | 1-3mm | Material: | Steel And Air Cylinder |
| High Light: | Candy Window Rigid Box Making Machine 1mm,Rigid Box Making Machine 3mm,3mm paper box making machine |
||
The latest technology gift box making machine from Longxingsheng.
Whole line setting time within 45-60 minutes. So that can meet different order quantity request. What`s more, it is wide working size. Max box length is 600mm, max box height is 400mm, max height is 120mm, it can help you gain more orders with this smart adjusting machine.
This machine is best choice for rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine adjusting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
