Product Details:
|
| Products Name: | Automatic Smart High Speed Rigid Wedding Gift Preium Box Making Machine With Visual Positioning | Box Length: | 82-600mm |
|---|---|---|---|
| Box Width: | 66-400mm | Box Height: | 17-120mm |
| Positioning Accuracy: | 0.02mm | Paper Thickness: | 80-340gsm |
| Cardboard Thickness: | 1-4mm | Material: | Steel |
| Warranty: | One Year | ||
| High Light: | Wedding Gift Box Making Machine,Rigid Gift Box Making Machine,paper box making machine 80gsm |
||
What is the dreaming speed of one automatic gift box making line in your mind? 10-20 pcs/min, 20-30 pcs/min? Currently we have equipment the LS-1246D can producing the rigid box with highest speed at 45 pcs/min.
The max box folding length is 600mm, max wrapping width is 400mm, Max forming height is 120mm. Whole line applied the visual positioning technology in rigid box production. Ensured its high working speed and accurate, Whole working speed can be adjusted in one button. The intelligent setting has ensured it can change new size in the shortest time.
The LS-1246D is best equipment for rigid box, cardboard box, cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box prodcution.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutesContact Person: Ms. Lyla Lyu
