Product Details:
|
| Product Name: | LS-F7 Semi-Automatic Rigid Gift Box Wrapping Machine For Phone Boxes And Gift Boxes | Machine Dimension: | L1200*W1070*H3000mm |
|---|---|---|---|
| Working Speed: | ＜24pcs/min | Power: | 3.5kw/220V Single Phase |
| Machine Weight: | 1030kg | Edge Folding Length: | 1-100mm |
| Highlight: | Rigid Box Wrapping Machine 1mm,Rigid Box Wrapping Machine 100mm,shrink wrapping machine for boxes |
||
LS-F7 Semi-Automatic Rigid Gift Box Wrapping Machine For Phone Boxes And Gift Boxes
Because the wooden mold is laser cut, there will be black borders and burrs after processing, we must process it after we get the board. Basically, we use sandpaper or a sanding machine to remove burrs and polish a little at the same time, so that when the boxes fit the mold, it will meet the requirement. After polishing, the upper mold is covered with high temperature tape
Input the box length, width, height, cover paper width, top mold height, middle mold height and tucking in blade thickness. Then press caluate, machine will automaitc come to home position and move to setting position. Load a box to checking the setting and ensure each setting is fine. Then machine can start working. Whole process will cost 8 minutes.
Working process:
1. box positioning on glued paper
2. Tucking in and edge folding
3. Tucking-in and second floor air pressing
| Type | LS-F7 |
| Max box size | L430*W350*H110mm |
| Min box size | L80*W65*H10mm |
| Motor power/voltage | 3.2kw/220V |
| Air supply | 10L/min 0.6Mpa |
| Working speed | ≤20pcs/min |
| Machine dimension | L1200*W1120*H3100mm |
| Weight of machine | 1150kg |
Company introduction:
Longxingsheng Machinery Co.,Ltd is located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd. We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery`s research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.
Q: How could I pay?
A1: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q2: What is your packing way? Can I have the customized package?
A2: We have the standard export package. For more details about the customized package, please contact us.
Q3: What is the delivery lead time?
A3: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q4: Are you a factory or a trading company?
A4: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
