Product Details:
|
| Products Name: | Fully Automatic Samrt Rigid Box Making Machine Cardboard Box Making Machine For Shoe,Wine & Gift Box | Length Paper Size: | L135-800mm |
|---|---|---|---|
| Width Paper Size: | W120-600mm | Max Cardboard Size: | L750*W500mm |
| Min Cardboard Size: | L100*W130mm | Max Box Size: | 600*400*120mm |
| Min Box Size: | 80*65*15mm | Feature: | Automatic & High Accuracy |
| Highlight: | Shoe Rigid Box Making Machine,135mm Rigid Box Making Machine,120mm Cardboard Box Making Machine |
||
LS-1246D is a full automatic intelligent rigid box-making machine. You only need to input the box size what you want to make on the touch screen, then the computer will automatically calculate that the machine will complete the whole process of box-making
The whole rigid box making process including the box corner pasting, paper feeding & gluing, paper & box positioning.Fanily is the box forming. This machine has applied visual positioning for easy and high accurate YAMAHA robotic arm. Automatic setting in the double forming station make the whole machine setting time reduce grealty.
The LS-1246D is best choice to make rigid box&cardboard box.such as cosmetic box, ring box, shoe box, lip and bottom box, jewelrry box, phone box & wine box.
| Type | LS-1246D |
| Paper size(max) | L800*W600mm |
| paper size(min) | L135*W100mm |
| Max cardboard size | L760*W560mm |
| Min cardboard size | L120*W100mm |
| Box size(length) | L100-600mm |
| Box size(width) | W60-400mm |
| Box size(height) | H15-120mm |
| Paper thickness | 80-350g/m2 |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Turn in depth | 15-80mm |
| Working speed | 15-45 pcs/min |
| Motor power | 13kw/380v 3phase |
| Heating power | 8kw |
| Air pressure | 40L/min 0.8MPa |
| Weight of machine | 4300kg |
| Machine dimension | L6600*W4200*H3000mm |
Machine setting time: Short in 45 minutes.save the working time.Contact Person: Ms. Lyla Lyu
