Product Details:
|
| Product Name: | Multi-Function Machine For Packaging Fields - Make Book Cover & Book Shape Box | Warranty: | 1 Year |
|---|---|---|---|
| Type: | Multi-Function Packaging Machine | Automatic Grade: | Automatic |
| Colour: | Black & White | Speed: | 15-35 Pcs/min |
| Application: | Rigid Box/hard Cover/Case Positioning | Dimension(L*W*H):: | L5980*W3180*H2100 |
| Weight: | 2200kg | Power: | 380V |
| Highlight: | Multifunctional book cover making machine,35pcs/min book cover making machine,35pcs/Min hard cover maker machine |
||
Multi-Function Machine For Packaging Fields - Make Book Cover & Book Shape Box
Introduction:
Multi-Function Machine For Packaging Fields - Make Book Cover & Book Shape Box is a hot model recently, because it is a hot model for book shape box making, because it is not only can make the rigid box, but also can make the book cover, it is a multi-funtion package machine which is flexible solution for box making.
500 mm high paper can be stacked on the paper feeding table to reduce the time of stopping and feeding as much as possible. When loading paper, we need to adjust the position of each part of the mechanism according to the size of the paper. The console can be moved up and down through the buttons on the right side of the table (see the buttons section for details).
| Type | LS-450plus |
| Paper size (Max) | L800*W600mm |
| Paper size (Min) | L135*W100mm |
| Max box size | L600*W400*H120mm |
| Min box size | L80*W65*H15mm |
| Book cover (Max) | L750*W450mm |
| Book cover (Min) | L150*W100mm |
| Paper thickness | 100-350g/㎡ |
| Paper stacking height | 280mm |
| Motor power / voltage | 7.5kw/380v, 3 phase |
| Heating power | 8kw/380v, 3 phase |
| Air supply | 10L/min 0.6Mpa |
| Working speed | 15-45 sheets/min |
| Machine dimension | L5980*W3180*H2100mm |
| Weight of machine | 2100kg |
Company profile:
Dongguan Longxingjian Intelligent Equipment Co.,Ltd
We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery's research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.
We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.
Our service:
Pre-sale service:
* Inquiry and consulting support.
* Sample testing support.
* Factory visit.
* Order confirmation
After-sale service:
* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* On-line technology support.
* Free machine parts replacement during warranty.
* Whole life of machine service.
