Cardboard Box Making Positioning Machine With Double Basler Cameras

Cardboard Box Making Positioning Machine With Double Basler Cameras
Cardboard Box Making Positioning Machine With Double Basler Cameras
Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras Cardboard Box Making Positioning Machine With Double Basler Cameras

Large Image :  Cardboard Box Making Positioning Machine With Double Basler Cameras

Product Details:
Place of Origin: China
Brand Name: Longxingsheng
Certification: CE, ISO9001
Model Number: LS-450Plus
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: With paper,film and by wooden crate.
Delivery Time: 7-16 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 14 sets/month
Contact Now

Cardboard Box Making Positioning Machine With Double Basler Cameras

Description
Product Name: LS-450plus Hardcover Positioning Machine Application: Rigid Box/Hard Cover/ Case/Cardboard Positioning
State: New Country Of Origin: China
Power Type: Pneumatic Core Selling Point:: High-accuracy
Warranty Period Of Core Components: 1Year Core Components:: PLC、motor
Production:: 15-45sheet/min Machine Size: L5980*W3180*H2100mm
Highlight:

Cardboard Box Making Positioning Machine

,

Double Basler Cameras Positioning Machine

,

Double Basler Cameras Positioning Equipment

Automatic Cardboard Box making Positioning Machine Paper Lining


Main features

1. High speed, Max speed is 45 pcs/min.
2. Easy operation, the min setting time of change model is 7 minutes.
3. No-move camera when change sizes.
4. Double Germany Basler cameras (ten million pixels).
5. Dual feeding system, one button change box feeding to hardcover feeding system.
6. Anti-leaking gluing system.
7. Panasonic Servo motor feeding system. 8. Storage function for the positioning part, easy to adjustment
9. Yamaha Robotic arm.
10. Box detecting system.
Visual positioning machine is a core parts for rigid box production. It is widely applied since 2017. As the visual positioning has stable and high positioning accuracy than manual positioning. It has faster model changing speed than sensor positioning. The fastest setting time of visual positioning part is 7 minutes. Nowadays, the visual positioning has been applied in the production of rigid box, gift box, shoe box, cellphone box, cosmetic box, ring box, jewelry box, tea box etc. It is also able to positioning the hardcover, some customer able to using visual positioning for small case order.LS-450 Plus is a dual functional visual positioning machine. It is able to positioning the rigid box and hardcover. The working model able to change by one button. The visual positioning system is able to be upgrade. Whole line able to be upgraded to fully automatic line if need.

Products Description

Cardboard Box Making Positioning Machine With Double Basler Cameras 0

Cardboard Box Making Positioning Machine With Double Basler Cameras 1



Price vary with raw material cost, please contact our sales for latest prices.



Machine model
LS-450 Plus
Paper size(max)
L800*W600mm
paper size (min)
L150*W100mm
Box length
80-600mm
Box width
65-400mm
Box height
15-120mm
Paper thickness
100-350g/㎡
Cardboard thickness
0.5-3mm
Working speed
≤45sheets/min
Positioning accuracy
≤0.1mm
Motor power
7.5 kw/380v 3 phase
Heating power
8 kw
Air pressure
10L/min 0.6MPa
Weight of machine
2100kg
Machine dimension
L5980*W3180*H2100mm



Company Profile



Dongguan Longxingjian Intelligent Equipment Co.,Ltd



We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd. We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery`s research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.

Cardboard Box Making Positioning Machine With Double Basler Cameras 2
